UNIQUE FEATURES |
|
|
- Portable,
Attractive & Sleek Design.
- Low Cost, Low
Maintenance.
- Automatic low
Battery cut-off.
- Highly Reliable &
Based on Latest Technology.
- Suitable for home,
office , shops & Movable shops.
- Backup mode
Protected against overload, short ckt etc.
- Multi features
like FM ,Night LED light , Mobile Charger etc.
(optional)
- Soft start backup
mode
|
|
|
Click on image for large
view |
TECHNICAL SPECIFICATIONS |
Model: |
CFL
UPS |
Capacity : |
50
VA/ 40 Watt |
Battery Low cut-off : |
9.9± 0.1 V |
Battery Boost Voltage: |
13.8± 0.2 V |
Battery Recharge time: |
8 to
10 Hrs |
Battery Charger Range: |
125
V to 275 V |
Battery Charging Current: |
0.5
Amp to 0.8 Amp |
Battery : |
In-built 12 V- 7.2 Ah (1No.)SMF Dry Type |
Battery Backup TIme: |
6
Hrs on 1 CFL - 15 Watts (on full Charged Battery
Condition) |
|
|
|
|
|
Click on image for large
view |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Click on image for large
view |
Click on image for large
view |
Click on image for large
view |
|
|
